Rotary Tailstocks

Rotary Tailstocks

TJR Rotary Tailstocks

The rotary tailstock is ideal for applications that involve large heavy work pieces or for use with a tombstone or fixture plate. The rotary tailstock uses a pneumatic or hydraulic brake system to ensure the work piece or fixture remains rigid during the machining process.

  • Support longer and heavier workpieces
  • Become a more flexible shop
  • Support a tombstone or fixture plate to hold multiple workpieces

Specifications

Item / Model
Table Diameter
mm / inch
Center Height in Vertical
mm / inch
Overall Height in Vertical
mm / inch
Thru-hole
mm / inch
Width of T-slot
mm / inch
Width of Guide Block
mm
Clamping Force
kg*m/ft*lbs.
N.W.
kg / lbs.

RTA-125

Request a Quote

Ø125 / 4.92″

110 / 4.33″

187 / 7.36

Ø125 / 4.92″

12h7

14h7

13

18 /40

RTA-170

Request a Quote

Ø125 / 4.92″

135 / 5.31″

230 / 9.05″

Ø125 / 4.92″

12h7

14h8

31

29/64

RTA-210

Request a Quote

Ø125 / 4.92″

160 / 6.29″

265 / 10.43″

Ø125 / 4.92″

12h7

14h9

31

35/77

RTA-250

Request a Quote

Ø125 / 4.92″

160 / 6.29″

285 / 11.22″

Ø125 / 4.92″

12h7

14h10

35

57/126

RTA-400A

Request a Quote

Ø125 / 4.92″

255 / 10.03″

455 / 17.91″

Ø125 / 4.92″

12h7

14h11

115

106/234

RTH-210

Request a Quote

Ø125 / 4.92″

160 / 6.29″

265 / 10.43″

Ø125 / 4.92″

12h7

14h12

35

35/77

RTH-255

Request a Quote

Ø125 / 4.92″

160 / 6.29″

287.5 / 11.31″

Ø125 / 4.92″

12h7

14h13

70

57/126

RTH-320

Request a Quote

Ø125 / 4.92″

210 / 8.26″

370 / 14.56″

Ø125 / 4.92″

14h7

14h14

115

83/183

RTH-400

Request a Quote

Ø125 / 4.92″

255 / 10.03″

455 / 17.91″

Ø125 / 4.92″

14h7

14h15

200

106/234

RTH-500

Request a Quote

Ø125 / 4.92″

310 / 12.20″

560 / 22.04″

Ø125 / 4.92″

14h7

14h16

200

199/438

RTH-630

Request a Quote

Ø125 / 4.92″

400 / 15.74″

715 / 28.14″

Ø125 / 4.92″

14h7

14h17

200

243/535

RTH-800

Request a Quote

Ø125 / 4.92″

470 / 18.5″

885 / 34.84″

Ø125 / 4.92″

14h7

14h18

200

247/544

Frequently Asked Questions About Tailstocks

Tailstocks are a machine tool accessory used to support long parts on lathe or rotary tables.

Maybe — depending on the size of the part. If a short-length piece is being machined, a tailstock may not be necessary. For a long, slender piece — such as rifle barrel — using a tailstock allows for more accurate machining without distortion or chatter. Read more

Use an indicator sweep of the tailstock quill, with the indicators mounted to either the lathe spindle or the rotary table faceplate. The center of the tailstock should be aligned with the center of the spindle if it comes from the factory. If added to a rotary table, the center height of the tailstock should align to the center height of the rotary table. Tailstocks can be adjusted side to side, but if the center height is off, add shims to adjust it higher or remove material to bring it lower.

There are manual tailstocks; automatic tailstocks, which may be hydraulic or pneumatic; tailstocks with built in live centers; and rotary table tailstocks, which looks more like a another rotary table and are built to support heavy parts.

There are:

Dead centers, which do not turn and are typically used on manual machine tools and rotary table tailstocks.

Live centers, which have built in bearings and are often used on CNC machines and when higher RPMs are needed.
